Ceramic for Process Pressure Applications

Ceramic Measuring Cell for Differential Pressure

Filling liquid in a
single chamber

Basic ceramic body

Thick ceramic
membrane for
corrosive and
abrasive media

Capactive
electrodes

Integrated temperature
sensor for self-monitoring

Resistant to load changes

Wear-resistant

Corrosion-resistant

Long-term stability

Monitoring of functions

Ceramic for Process Pressure Applications

Atmospheric
Pressure

Basic body

Membrane

Relative pressure cell

Pressure

Dry measuring cell

Up to 100 times overload-proof

Fully suitable for use in a vacuum

Resistant to load changes

Wear-resistant / corrosion-resistant

Long-term stability (± 0.05%/year)

Absolute pressure cell

Pressure

For more information: Endress+Hauser GmbH
